GT42 / GT44 - Measuring probe for large measurement ranges with low resolution of measured values.
Designs:132245.0100:
GT61Normal version, stroke 10.3 mm, measuring pin lifting mechanical, cable axial
132245.0200:
GT 62Normal version, stroke 10.3 mm, measuring pin lifting vacuum, cable radial
Features:- Version with protection bellows
- ball lead
- Clamping shaft Ø 8 mm
- Cable length 2 m
- Separated from shaft measuring pin
- Exchangeable measuring insert M2.5 with carbide ball Ø 3 mm
Package contents:Delivered with inspection report.
Version with coupling - without cable
Appropriate Measuring Inserts:
124008 Measuring inserts M2.5 FUTURO
124010 Measuring inserts M2.5
710140 Measuring insert for comparator M 2.5 VOH
735820 Polymer dial gauge feeler TECHNIWATCH
